ZTX451 Transistor NPN 60V Medium Power Transistor

SKU 551624

MPN: ZTX451

Availability:
19 in stock
Original price £1.53 - Original price £1.53
Original price
£1.53 Inc VAT
£1.53 - £1.53
Current price £1.53 Inc VAT

The ZTX451 transistor is a 60V silicon NPN medium power transistor with planar construction. Supplied in TO-92 packaging. For further technical specifications please refer to the attached datasheet.

  • 1A continuous current
  • NPN Small signal transistor
  • Collector Base Voltage 80V
  • NPN Silicon Planar Medium Power Transistor
  • 60V 1A TO-92
  • Specification
    Back order lead time 5 Days
    Collector base voltage 80V
    Collector current 1A
    Collector emitter saturation voltage 350mV
    Collector emitter voltage 60V
    Dc current gain 50
    Maximum operating temperature 200°C
    Mounting type Through Hole
    Package TO92
    Power dissipation 1W
    Transistion frequency 150MHz
    Type NPN
