VTX-146-030-218 Toroidal Transformer 30VA 0-18V Vigortronix

SKU 487165

MPN: VTX-146-030-218

Availability:
10 in stock
Original price £17.72 - Original price £17.72
Original price
£17.72 Inc VAT
£17.72 - £17.72
Current price £17.72 Inc VAT
The VTX-146-030-218 is a high quality toroidal transformer featuring dual primary and secondary windings. The transformer features thermal fuses fitted to each primary winding, and a very low level radiated magnetic field. The transformers are widely used in industrial power, home appliances, instrumentation, communication and civil applications.

  • Dual primary winding: 115V+115V
  • Dual secondary winding: 0-18V 0-18V
  • Power: 30VA
  • Supplied with mounting kit
  • Dimensions: 33 x 74mm (Height x Diameter)
  • Compliant standards: EN61558, EN60950, UL, C-UL, UKCA and CE
  • Specification
    Back order lead time 5 Days
    Diameter 74mm
    Height 33mm
    Output current 0.83A
    Power 30VA
    Primary voltage 2 x 115V
    Regulation 14%
    Secondary voltage 2 x 18V
    Weight 450g
