VTX-146-015-206 Toroidal Transformer 15VA 0-6V Vigortronix

SKU 487157

MPN: VTX-146-015-206

Availability:
Out of stock
Sold out
Original price £14.74 - Original price £14.74
Original price
£14.74 Inc VAT
£14.74 - £14.74
Current price £14.74 Inc VAT
The VTX-146-015-206 is a high quality toroidal transformer featuring dual primary and secondary windings. The transformer features thermal fuses fitted to each primary winding, and a very low level radiated magnetic field. The transformers are widely used in industrial power, home appliances, instrumentation, communication and civil applications.

  • Dual primary winding: 115V+115V
  • Dual secondary winding: 0-6V 0-6V
  • Power: 15VA
  • Supplied with mounting kit
  • Dimensions: 33 x 65mm (Height x Diameter)
  • Compliant standards: EN61558, EN60950, UL, C-UL, UKCA and CE
  • Specification
    Back order lead time 5 Days
    Diameter 65mm
    Height 33mm
    Output current 1.25A
    Power 15VA
    Primary voltage 2 x 115V
    Regulation 16%
    Secondary voltage 2 x 6V
    Weight 330g
