VTX-126-012-224 Chassis Mount Transformer 230V 12VA 24V+24V Vigortronix
by Vigortronix
SKU 480247
MPN: VTX-126-012-224
Availability:
Only 3 left!
Original price
£16.45
-
Original price
£16.45
Original price
£16.45
£16.45
-
£16.45
Current price
£16.45
The VTX-126-012-224 is a high quality chassis mount transformer featuring a single 230V primary winding and 24V twin secondary winding. The transformer features 12VA power and can be connected in series or parallel.
Double section metric bobbins Primary winding: 230V Secondary winding: 24V+24V Power: 12VA Dielectric strength: 3750Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 5 Days |
| Dielectric Strength | 3750Vrms |
| Height | 45mm |
| Length | 60mm |
| Output Current | 0.25A |
| Power | 12VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 24V+24V |
| Weight | 390g |
| Width | 50mm |
