VTX-126-006-224 Chassis Mount Transformer 230V 6VA 24V+24V Vigortronix
by Vigortronix
SKU 480239
MPN: VTX-126-006-224
Availability:
7 in stock
Original price
£12.52
-
Original price
£12.52
Original price
£12.52
£12.52
£12.52
-
£12.52
Current price
£12.52
The VTX-126-006-224 is a high quality chassis mount transformer featuring a single 230V primary winding and 24V twin secondary winding. The transformer features 6VA power and can be connected in series or parallel.
Double section metric bobbins Primary winding: 230V Secondary winding: 24V+24V Power: 6VA Dielectric strength: 3750Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 5 Days |
| Dielectric Strength | 3750Vrms |
| Height | 36mm |
| Length | 45mm |
| Output Current | 0.13A |
| Power | 6VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 24V+24V |
| Weight | 170g |
| Width | 37mm |
