VTX-120-5412-220 PCB Transformer 230V 12VA 20V+20V Vigortronix
by Vigortronix
SKU 480273
MPN: VTX-120-5412-220
Availability:
Only 2 left!
Original price
£8.77
-
Original price
£8.77
Original price
£8.77
£8.77
-
£8.77
Current price
£8.77
The VTX-120-5412-220 is a high quality PCB mount transformer featuring a single 230V primary winding and 20V twin secondary winding. The transformer features 12VA power and is suitable for 50/60Hz applications.
Primary winding: 230V Secondary winding: 20V+20V Power: 12VA 50/60Hz UL94-V0 material Temperature Class: - Class B (130°C) Dielectric strength: 4200Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 5 Days |
| Dielectric Strength | 4200Vrms |
| Height | 39mm |
| Length | 54mm |
| Output Current | 0.3A |
| Power | 12VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 20V+20V |
| Weight | 340g |
| Width | 45mm |
