VTX-120-5412-206 PCB Transformer 230V 12VA 6V+6V Vigortronix
by Vigortronix
SKU 480267
MPN: VTX-120-5412-206
Availability:
Only 5 left!
Original price
£8.00
-
Original price
£8.00
Original price
£8.00
£9.60
£9.60
-
£9.60
Current price
£9.60
The VTX-120-5412-206 is a high quality PCB mount transformer featuring a single 230V primary winding and 6V twin secondary winding. The transformer features 12VA power and is suitable for 50/60Hz applications.
Primary winding: 230V Secondary winding: 6V+6V Power: 12VA 50/60Hz UL94-V0 material Temperature Class: - Class B (130°C) Dielectric strength: 4200Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 7 |
| Dielectric Strength | 4200Vrms |
| Height | 39mm |
| Length | 54mm |
| mnml.volume pricing tiers | [{"qty":10,"price":713,"type":"amount"},{"qty":25,"price":672,"type":"amount"},{"qty":50,"price":632,"type":"amount"},{"qty":100,"price":600,"type":"amount"}] |
| MOQ | 1 |
| Output Current | 1A |
| Power | 12VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 6V+6V |
| Weight | 340g |
| Width | 45mm |
