VTX-120-3803-212 PCB Transformer 230V 3VA 12V+12V Vigortronix
by Vigortronix
SKU 480252
MPN: VTX-120-3803-212
Availability:
8 in stock
Original price
£6.34
-
Original price
£6.34
Original price
£6.34
Inc VAT
£6.34
-
£6.34
Current price
£6.34
Inc VAT
The VTX-120-3803-212 is a high quality PCB mount transformer featuring a single 230V primary winding and 12V twin secondary winding. The transformer features 3VA power and is suitable for 50/60Hz applications.
Primary winding: 230V Secondary winding: 12V+12V Power: 3VA 50/60Hz UL94-V0 material Temperature Class: - Class B (130°C) Dielectric strength: 4200Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back order lead time | 5 Days |
| Dielectric strength | 4200Vrms |
| Height | 30mm |
| Length | 38mm |
| Output current | 0.13A |
| Power | 3VA |
| Primary voltage | 230VAC |
| Secondary voltage | 12V+12V |
| Weight | 140g |
| Width | 32mm |
