VTX-120-3803-2045 PCB Transformer 230V 3VA 4.5V+4.5V Vigortronix
by Vigortronix
SKU 480248
MPN: VTX-120-3803-2045
Availability:
8 in stock
Original price
£5.63
-
Original price
£5.63
Original price
£5.63
Inc VAT
£5.63
-
£5.63
Current price
£5.63
Inc VAT
The VTX-120-3803-2045 is a high quality PCB mount transformer featuring a single 230V primary winding and 4.5V twin secondary winding. The transformer features 3VA power and is suitable for 50/60Hz applications.
Primary winding: 230V Secondary winding: 4.5V+4.5V Power: 3VA 50/60Hz UL94-V0 material Temperature Class: - Class B (130°C) Dielectric strength: 4200Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back order lead time | 5 Days |
| Dielectric strength | 4200Vrms |
| Height | 30mm |
| Length | 38mm |
| Output current | 0.33A |
| Power | 3VA |
| Primary voltage | 230VAC |
| Secondary voltage | 4.5V+4.5V |
| Weight | 140g |
| Width | 32mm |
