UTi721M Professional Android Thermal Imaging Smartphone Camera Module Uni-T
by Uni-T
SKU 488618
MPN: UTi721M
Availability:
Out of stock
Sold out
Original price
£299.02
-
Original price
£299.02
Original price
£299.02
Inc VAT
£299.02
-
£299.02
Current price
£299.02
Inc VAT
The UTi721M is a professional thermal camera module for smartphones, which is compact, portable, and easy to operate through connecting with mobile phones. It's 256x192 IR resolution provides clear image with a fast response. The UTi721M features a wide temperature measurement range -20_ ~ 550_. It includes two measurements modes for elevated skin temperature inspection and industry applications. Users can troubleshoot HVAC problems or investigate heat source issues around the house and hidden issues faster and easier with this thermal camera module. It is a perfect tool for DIY homeowners,outdoor lovers, engineers, contractors and builders etc.
IR resolution: 256x192 Temperature measurement range: -20℃ to 550℃ / -4℉ to 1022℉ Measurement modes: Industry, EST(Elevated Skin Temperature) Auto alarm for high/low temperature Auto tracking for hot spot/cold spot On screen analyzer: 3 Points/3 Lines/3 Rectangles Image capture Video recording Colour palettes: 7(White hot, Black hot, Red hot Ironbow, Lava, Rainbow, Rainbow HC) Phone: Android (USB Type-C interface) 1m extension cable 1m drop proof
Specification
| Accuracy | ±2℃ or ±2% |
| Back order lead time | 10 Days |
| Colour palettes | 7 |
| Connectivity | USB-C |
| Field of view | 56°×42.2° |
| Focus | Focus free |
| Frame rate | ≤25Hz |
| Image modes | Thermal, Fusion, PIP |
| Ir resolution | 256x192 |
| On screen analyzer | 3 Points, 3 Lines, 3 Rectangles |
| Spatial resolution | 3.8mrad |
| Spectral range | 8~14µm |
| Temperature alarm | Yes |
| Temperature range | -20℃ to 550℃ |
| Thermal sensitivity | ≤50mK @ 25℃ |
