UTD2025CL Digital Storage 2 Channel Analog Oscilloscope 25MHz Uni-T

by Uni-T
SKU 488959


Only 2 left!
Original price £200.87 - Original price £200.87
Original price
£200.87 Inc VAT
£200.87 - £200.87
Current price £200.87 Inc VAT
The UTD2025CL is a market-proven economical digital oscilloscope. This series of digital oscilloscopes has excellent technical indicators and can meet the main needs of basic testing. The front panel design is clear and intuitive, fully in line with the traditional instrument usage habits, and is convenient for users to operate.

  • Bandwidth: 25MHz
  • Real time sample rate: 250MSa/s
  • Waveform capture rate: 2000 wfms/s
  • 2 analog channels
  • Maximum memory depth: 25 kpts
  • 7" display
  • Wider display range
  • Variety of automatic measurement parameters and mathematical operation functions
  • Multiple trigger functions
  • Multi-frequency standard square wave
  • Waveform phase measurement
  • Specification
    Back order lead time 10 Days
    Bandwidth 25MHz
    Channels 2 Analogue
    Digitalanalogue Digital
    Display 7 Inch TFT LCD
    Memory depth 25 kpts
    Rise time <14ns
    Sampling rate 250MSa/s
    Vertical range 1mV/div to 20V/div
    Waveform capture rate 2000 wfms/s
