UPO2104 Digital Storage 4 Channel Analog Oscilloscope 100MHz Uni-T

by Uni-T
SKU 488946

MPN: UPO2104

Availability:
Out of stock
Sold out
Original price £959.44 - Original price £959.44
Original price
£959.44 Inc VAT
£959.44 - £959.44
Current price £959.44 Inc VAT
The UPO2104 digital phosphor oscilloscope is a multifunctional and high-performance oscilloscope based on UNI-T's original Ultra Phosphor technology. It provides the combination of ease of use, excellent technical indicators and many functional features. It can help users complete the measurement work faster and more efficiently. It is an oscilloscope designed for general design / debugging / testing needs in many fields, such as communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, R&D, education, etc. Fast Acquire technology can accurately capture abnormal events such as video, jitter, noise and low wave signals.

  • Bandwidth: 100MHz
  • Real time sample rate: 2GSa/s
  • Waveform capture rate: 1.000,000wfms/s
  • 4 analog channels
  • 4M pts enhanced FFT
  • Web control
  • LA logic analyzer
  • Bode plot
  • AWG function arbitrary waveform generator
  • Area trigger
  • Full memory hardware decoding
  • Rich trigger function
  • Memory depth 56Mpts per channel
  • Channel split screen function
  • 256-level grayscale display
  • Ultra high capture rate
  • XY mode
  • Rich measurement functions
  • 8-inch interactive touch screen
  • Specification
    Back order lead time 10 Days
    Bandwidth 100MHz
    Channels 4 Analogue
    Digitalanalogue Digital
    Display 8 Inch Touch Screen
    Memory depth 56Mpts
    Rise time <3.5ns
    Sampling rate 2GSa/s
    Vertical range 500uV/div to 20V/div
    Waveform capture rate 1,000,000 wfms/s
