T1618 Techna 18A Thermal Panel Mount Circuit Breaker

by Techna
SKU 485173

MPN: T1618

Availability:
25 in stock
Original price £2.78 - Original price £2.78
Original price
£2.78 Inc VAT
£2.78 - £2.78
Current price £2.78 Inc VAT
18A panel mount circuit breaker from the Techna T16 series, featuring quick connect terminals and manual reset. The breaker comes supplied with nameplate and fixing nut making it suitable for a wide range of applications.

  • 18A current rating
  • 250Vac voltage rating
  • Trip time at 200% 5 to 30s
  • 11mm panel cut-out diameter
  • 35 x 14.6 x 47.2mm dimensions
  • UL, CSA, VDE approved
  • Specification
    Back order lead time 5 Days
    Current rating 18A
    Interrupting capacity 1000A
    Mounting style Panel
    Panel cut out 11mm
    Voltage rating 250V
