RV8H-L-D24 DIN Mount 24VDC 8mm Slim Interface Relay Screw Terminals SPDT IDEC

by IDEC
SKU 490245

MPN: RV8H-L-D24

Availability:
10 in stock
Original price £11.92 - Original price £11.92
Original price
£11.92 Inc VAT
£11.92 - £11.92
Current price £11.92 Inc VAT
The RV8H-L-D24 is a interface relay by IDEC providing a compact solution for general purpose requirements. The relay can be used as a universal interface between the controller and the actuator to switch small and medium size loads. Installation time is greatly reduced with pre-assembled relays and socket. The relays are suitable for PLC and other controller outputs, industrial automation, panel builders, assembly machine applications, and other that require a high switching capability in a compact space.

  • Coil voltage: 24VDC
  • Allowable switching curent: 6A
  • Contact configuration: SPDT
  • DIN rail mounting
  • Screw terminals
  • Universal AC/DC socket with surge suppression and green LED indicator
  • Reverse polarity protected
  • Release lever for easy locking and removal of relay
  • Dimensons: 88.0 x 69.6 x 6.0mm (Height x depth x width)
  • Specification
    Ambient temperature -40°C to +70°C
    Back order lead time 130 Days
    Coil resistance 2270Ω
    Coil voltage 24VDC
    Contact arrangement SPDT
    Maximum continuous voltage 26.4VDC
    Maximum switching current 6A
    Moq 1
    Mounting type DIN Rail
    Power consumption 0.25W
    Rated load 6A 250VAC, 6A 30VDC
    Terminal type Screw
