Red 5050 SMD PLCC-6 LED Water Clear 500mcd

SKU 311195

MPN: TY-5050UR3-500

Availability:
3725 in stock
Original price £0.17 - Original price £0.17
Original price
£0.17 Inc VAT
£0.17 - £0.17
Current price £0.17 Inc VAT
Surface mount LEDs in a 5050 package with a high luminous intensity suitable for a wide range of applications including backlighting and indicator uses.

  • Water clear lens
  • 5050 PLCC-6 package
  • 120° viewing angle
  • UV resistant
  • Dimensions: 5.0 x 5.0 x 1.6mm
  • Supplied on tape packaging
  • Specification
    Back order lead time 45 Days
    Colour Red
    Forward current 30mA
    Forward voltage 2.1V
    Height 1.6mm
    Length 5.0mm
    Lens colour Clear
    Luminous intensity 500mcd
    Moq 5
    Mounting style Surface Mount
    Number of pins 6
    Operating temperature -40°C to 85°C
    Package 5050
    Packaging Cut-Tape
    Power dissipation 60mW
    Viewing angle 120°
    Wavelength 635nm
    Width 5.0mm
