(On)-Off-(On) SPDT Toggle Switch 250V AC 15A

SKU 112041

MPN: 112041

Availability:
1841 in stock
Original price £2.72 - Original price £2.72
Original price
£2.72 Inc VAT
£2.72 - £2.72
Current price £2.72 Inc VAT
Momentary toggle switch with an (On)-Off-(On) action suitable for panel mounting.

  • (On)-Off-(On) operation
  • SPDT contacts
  • 6.3mm quick connect terminals
  • 12mm panel cut-out
  • Secured by nut
  • Maximum Panel Thickness: 5mm
  • Dimensions: 55.5 x 29.6 x 16mm (Height x Length x Width)
  • Specification
    Actuation Momentary
    Back order lead time 120 Days
    Contact configuration SPDT
    Contact rating 15A 250VAC
    Current rating 15A
    Electrical life 100,000 Cycles
    Illuminated No
    Mounting style Panel
    Number of poles 1
    Number of positions 3
    Operating temperature -25°C to +80°C
    Panel cut out 12mm
    Protection level IP40
    Switch operation (On)-Off-(On)
    Terminal type Quick Connect
    Voltage rating 250VAC
