Off-(On) Momentary Prewired Foot Switch SPST
SKU 486908
MPN: 486908
Availability:
151 in stock
Original price
£2.76
-
Original price
£2.76
Original price
£2.76
Inc VAT
£2.76
-
£2.76
Current price
£2.76
Inc VAT
Prewired soft touch foot switch featuring SPST contacts and momentary operation. The switch is easy to install and features a 3A 250V rating, suitable for guitar applications.
Off-(On) momentary operation SPST contacts 160mm tail leads 12mm panel cut-out Soft touch operation (no clicking)
Specification
| Actuation | Momentary |
| Back order lead time | 40 Days |
| Contact configuration | SPST |
| Contact rating | 6A 125VAC, 3A 250VAC |
| Current rating | 6A @ 125VAC |
| Electrical life | 20,000 Cycles |
| Illumination colour | Non Illuminated |
| Number of poles | 1 |
| Number of positions | 2 |
| Operating force | 24N |
| Operating temperature | -25°C to +80°C |
| Panel cut out | 12mm |
| Switch operation | Off-(On) |
| Terminal type | Flying Leads |
| Voltage rating | 250VAC |
