KL313AXKA265NXXT3 On-Off Green 24V illuminated Locking Power Rocker Switch SPDT
by APEM
SKU 490025
MPN: KL313AXKA265NXXT3
Availability:
40 in stock
Original price
£22.62
-
Original price
£22.62
Original price
£22.62
Inc VAT
£22.62
-
£22.62
Current price
£22.62
Inc VAT
The KL313AXKA265NXXT3 is a 24V power rower switch manufactured by APEM, featuring a locking mechanism to prevent against accidental operation. The switch features green 24V illumination with a yellow and red actuator.
On-Off operation SPDT contacts Green 24V illumination One protected position 6.35mm quick connect terminals Rating: 10A 24VDC Panel cut-out: 36.8 x 21.08mm Panel thickness: 0.8 to 4.6mm
Specification
| Actuation | Latching |
| Contact configuration | SPDT |
| Contact material | Silver |
| Contact rating | 10A 24VDC |
| Current rating | 10A |
| Illuminated | Yes |
| Illumination colour | Green |
| Illumination voltage | 24V |
| Moq | 1 |
| Mounting style | Panel |
| Number of poles | 1 |
| Number of positions | 2 |
| Operating temperature | -40°C to +85°C |
| Panel cut out | 36.8 x 21.08mm |
| Panel thickness | 0.8mm to 4.6mm |
| Switch operation | On-Off |
| Terminal type | Quick Connect |
| Voltage rating | 24VDC |
