KBPC802 Bridge Rectifier Diode 8A 200V
SKU 552227
MPN: KBPC802
Availability:
78 in stock
Original price
£1.04
-
Original price
£1.04
Original price
£1.04
Inc VAT
£1.04
-
£1.04
Current price
£1.04
Inc VAT
KBPC802 miniature bridge rectifier diode featuring 8A average forward current and 200V repetitive peak reverse voltage, housed in a flame retardant UL 94V-0 plastic case suitable for mounting to printed circuit boards.
125A surge overload rating Low forward voltage drop Moulded plastic package Dimensions: 19.0mm x 19.0mm x 7.0mm (Width x Length x Height) Pitch: 12.7mm x 12.7mm
Specification
| Average rectified current | 8A |
| Back order lead time | 5 Days |
| Body dimensions | 19.0mm x 19.0mm x 7.0mm (Width x Length x Height) |
| Maximum dc blocking voltage | 200V |
| Maximum forward voltage | 1.1V |
| Maximum rms voltage | 140V |
| Mounting style | Through Hole |
| Operating temperature | -55°C to 125°C |
| Package | KBPC-8/10 |
| Packaging | Bulk |
| Peak reverse voltage | 200V |
| Peak surge current | 125A |
