IZMR3S42N APEM Black Metal 16mm Round Momentary NO Push Button Switch IP67
by APEM
SKU 490019
MPN: IZMR3S42N
Availability:
216 in stock
Original price
£22.90
-
Original price
£22.90
Original price
£22.90
Inc VAT
£22.90
-
£22.90
Current price
£22.90
Inc VAT
The IZMR3S42N is an illuminated rear mounting round sealed momentary push button switch with a 16mm bushing and SPST normally open contacts. The switch features IP67 protection rating and solder lug terminals. This makes the switch ideal for applications including automotive and marine.
Button colour: black Panel cut-out: 16.2mm Contacts: momentary SPST-NO Gold plated silver contacts Solder lug terminals Contact rating: 200mA 48VDC Protection rating: IP67 Maximum panel thickness: 3mm Dimensions: 20 x 25.4mm (diameter x height)
Specification
| Actuation | Momentary |
| Colour | Black |
| Contact configuration | SPST |
| Contact material | Gold Plated Silver |
| Contact rating | 200mA 48VDC |
| Current rating | 0.2A |
| Electrical life | 500,000 Cycles |
| Illuminated | No |
| Material | Nickel Plated Brass |
| Moq | 1 |
| Mounting style | Panel |
| Number of poles | 1 |
| Number of positions | 2 |
| Operating force | 6N |
| Operating temperature | -40°C to +85°C |
| Panel cut out | 16.2mm |
| Panel thickness | 3mm |
| Product series | IZ |
| Protection level | IP67 |
| Switch operation | Off-(On) |
| Terminal type | Solder |
| Voltage rating | 48VDC |
