Green Mushroom Momentary 19mm Metal Push Button Switch IP65 NO
SKU 490322
MPN: HBGQ19M-10/J/T/G
Availability:
46 in stock
Original price
£6.33
-
Original price
£6.33
Original price
£6.33
£6.33
£6.33
-
£6.33
Current price
£6.33
Green 19mm momentary vandal resistant push button switch featuring normally open SPST contacts. The switch features a red mushroom button and is constructed from an aluminium alloy. The switch features an IP65 protection rating and is suitable for a wide range of applications including security, control panels, industrial, automotive etc.
Off-(On) operation SPST-NO contacts Green mushroom button Panel cut-out: 19mm Panel thickness: 9mm max 2.8x0.5mm quick connect / solder terminals Rating: 5A 250V Protection rating: IP65 Head diameter: 27.7mm Dimensions: 35.7 x 27.7mm (height x diameter)
Specification
| Actuation | Momentary |
| Back Order Lead Time | 45 Days |
| Colour | Green |
| Contact Configuration | SPST |
| Contact Material | Silver Alloy |
| Contact Rating | 5A 250VAC |
| Current Rating | 5A |
| Electrical Life | 50,000 Cycles |
| Illuminated | No |
| Material | Aluminium Alloy |
| MOQ | 1 |
| Mounting Style | Panel |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Operating Temperature | -25°C to +65°C |
| Panel Cut Out | 19mm |
| Panel Thickness | 9mm Max |
| Protection Level | IP65 |
| Switch Operation | Off-(On) |
| Terminal Type | Quick Connect |
| Voltage Rating | 250VAC |
