Green 5050 SMD PLCC-6 LED Water Clear 3000mcd

SKU 311198

MPN: TY-5050PG3-3000

Availability:
4457 in stock
Original price £0.21 - Original price £0.21
Original price
£0.21 Inc VAT
£0.21 - £0.21
Current price £0.21 Inc VAT
Surface mount LEDs in a 5050 package with a high luminous intensity suitable for a wide range of applications including backlighting and indicator uses.

  • Water clear lens
  • 5050 PLCC-6 package
  • 120° viewing angle
  • UV resistant
  • Dimensions: 5.0 x 5.0 x 1.6mm
  • Supplied on tape packaging
  • Specification
    Back order lead time 45 Days
    Colour Green
    Forward current 25mA
    Forward voltage 3.2V
    Height 1.6mm
    Length 5.0mm
    Lens colour Clear
    Luminous intensity 3000mcd
    Moq 5
    Mounting style Surface Mount
    Number of pins 6
    Operating temperature -40°C to 85°C
    Package 5050
    Packaging Cut-Tape
    Power dissipation 105mW
    Viewing angle 120°
    Wavelength 520nm
    Width 5.0mm
