Blue 0805 SMD LED 200mcd 120°
by Toyo LED
SKU 311503
MPN: TY-Y0805BL1
Availability:
1827 in stock
Original price
£0.16
-
Original price
£0.16
Original price
£0.16
£0.16
£0.16
-
£0.16
Current price
£0.16
High brightness surface mount LEDs housed in industry standard 0805 package featuring a single chip. The LEDs offer a wide viewing angle and are suitable for a range of backlighting and other lighting applications.
Package: 2.0 x 1.25 x 0.8mm High brightness Water clear package Wide viewing angle Low power consumption
Specification
| Back Order Lead Time | 45 Days |
| Colour | Blue |
| Forward Current | 30mA |
| Forward Voltage | 2.8V |
| Height | 0.8mm |
| Length | 2.0mm |
| Lens Colour | Clear |
| Luminous Intensity | 200mcd |
| MOQ | 10 |
| Mounting Style | Surface Mount |
| Number of Pins | 2 |
| Operating Temperature | -40°C to +85°C |
| Package | 0805 |
| Packaging | Cut-Tape |
| Power Dissipation | 135mW |
| Viewing Angle | 120° |
| Wavelength | 467nm |
| Width | 1.25mm |
