AM-1009L 4mm Gold Bullet Connector Red Housing 32A AMASS
by AMASS
SKU 490405
MPN: AM-1009L.G.R
Availability:
980 in stock
Original price
£1.04
-
Original price
£1.04
Original price
£1.04
£1.04
£1.04
-
£1.04
Current price
£1.04
The AM-1009L is a 2 pin gold plated banana connector featuring a high temperature nylon housing and solder termination. The connectors design prevents short-circuit and the banana connectors are removable allowing easy wiring. The connectors are designed for a wide range of battery power applications including use with drones, RC vehicles, airsoft etc.
2 pins 4mm bullet connectors Contact material: Gold plated brass Housing material: nylon Current rating: 32A Wire size: 12AWG Length: 34.3mm
Specification
| Back Order Lead Time | 120 Days |
| Colour | Red |
| Contact Material | Gold Plated Brass |
| Contact Resistance | 0.65mΩ |
| Current Rating | 32A |
| Housing Material | Nylon |
| MOQ | 1 |
| Number of Poles | 2 |
| Operating Temperature | -20°C to 120°C |
| Size Details | 4mm |
| Termination Method | Solder |
| Voltage Rating | 500VDC |
| Wire Gauge | 12AWG |
