70°C Normally Closed Thermostat Thermal Temperature Switch Flat Terminals NC
SKU 484375
MPN: 484375
Availability:
57 in stock
Original price
£1.78
-
Original price
£1.78
Original price
£1.78
£1.78
£1.78
-
£1.78
Current price
£1.78
70°C automatic reset thermostat switch featuring normally closed contacts and flat terminals allow the switching to be mounted in shallow spaces.
Normally closed contacts Auto reset function Action temperature: 70°C Reset temperature: 55°C 6.3mm quick connect terminals Rating: 10A 250VAC
Specification
| Activation Temperature | 70°C |
| Back Order Lead Time | 45 Days |
| Contact Configuration | NC |
| Contact Rating | 10A 250VAC |
| Current Rating | 10A |
| Electrical Life | 100,000 Cycles |
| Mounting Style | Panel Mount |
| Number of Positions | 2 |
| Opening Temperature | 70°C |
| Operating Temperature | 220°C Max |
| Returning Temperature | 55°C |
| Temperature Tolerance | 3% |
| Terminal Type | Quick Connect |
| Voltage Rating | 250VAC |
