500K Linear Stereo Right Angle PCB 16mm Potentiometer

SKU 484836

MPN: 484836

Availability:
999 in stock
Original price £0.64 - Original price £0.64
Original price
£0.64 Inc VAT
£0.64 - £0.64
Current price £0.64 Inc VAT
500k linear stereo potentiometer featuring right angle PCB contacts and splined 6mm shaft.

  • Standard 16mm diameter size
  • 20% tolerance
  • Panel cut-out: 7mm
  • 5mm pitch
  • 15mm shaft length
  • Specification
    Back order lead time 45 Days
    Dimensions 17mm Diameter
    Maximum voltage 200V
    Mounting hole diameter 7mm
    Mounting type PCB
    Operating temperature -25°C to +70°C
    Pitch 5mm
    Power rating 0.125W
    Resistance 500KΩ
    Shaft diameter 6mm
    Taper Linear
    Termination type Pin
    Tolerance ±20%
    Total rotation 300°
