5-Way 3.81mm Vertical Pluggable Terminal Block Green 8A 300V
by PTR HARTMANN
SKU 487604
MPN: AKZ1700/5-3,81-GREEN
Availability:
400 in stock
Original price
£1.01
-
Original price
£1.01
Original price
£1.01
Inc VAT
£1.01
-
£1.01
Current price
£1.01
Inc VAT
5 pole pluggable terminal block manufactured by PTR HARTMANN, featuring a 3.81mm pitch and vertical wire entry. The terminal blocks are rated up to 8A, making them suitable for a wide range of PCB applications.
5 pole 3.81mm pitch Vertical wire entry Material: PA66 Rating: 8A 300V Wire size: 28-16AWG
Specification
| Back order lead time | 10 Days |
| Colour | Green |
| Contact material | Brass |
| Current rating | 8A |
| Housing material | PA66 |
| Mounting type | Cable Mount |
| Number of ways | 5 |
| Operating temperature | -40°C to +105°C |
| Pitch | 3.81mm |
| Termination method | Screw |
| Voltage rating | 300VAC |
| Wire range | 28-16AWG |
