4R7 Arcol 25W Aluminium Clad Resistor HS25

by Arcol
SKU 399014

MPN:

Availability:
Out of stock
Sold out
Original price £2.25 - Original price £2.25
Original price
£2.25 Inc VAT
£2.25 - £2.25
Current price £2.25 Inc VAT
Arcol 25W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.

  • High power to volume
  • Wound to maximise high pulse capability
  • 5% tolerance
  • Solder terminations
  • Features 2 mounting holes
  • Arcol HS series
  • Specification
    Back order lead time 10 Days
    Dimensions 51.0 x 28.0 x 14.6mm (Length x Width x Height)
    Heatsink area 535cm²
    Limiting element voltage 550V
    Mpn HS25 4R7 J
    Operating temperature -55°C to +200°C
    Packaging Bulk
    Power rating 25W
    Resistance 4.7Ω
    Temperature coefficient ±100ppm/°C
    Termination Solder Lug
    Tolerance ±5%
