470R Arcol 25W Aluminium Clad Resistor HS25
by Arcol
SKU 399020
MPN:
Availability:
19 in stock
Original price
£2.03
-
Original price
£2.03
Original price
£2.03
Inc VAT
£2.03
-
£2.03
Current price
£2.03
Inc VAT
Arcol 25W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.
High power to volume Wound to maximise high pulse capability 5% tolerance Solder terminations Features 2 mounting holes Arcol HS series
Specification
| Back order lead time | 10 Days |
| Dimensions | 51.0 x 28.0 x 14.6mm (Length x Width x Height) |
| Heatsink area | 535cm² |
| Limiting element voltage | 550V |
| Mpn | HS25 470R J |
| Operating temperature | -55°C to +200°C |
| Packaging | Bulk |
| Power rating | 25W |
| Resistance | 470Ω |
| Temperature coefficient | ±100ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
