2-Way 5.00mm Pin Strip Pluggable Terminal Block Grey 8A 300V

SKU 488474

MPN: AK130/02-5.0-GREY

Availability:
250 in stock
Original price £0.62 - Original price £0.62
Original price
£0.62 Inc VAT
£0.62 - £0.62
Current price £0.62 Inc VAT
2 pole pluggable terminal block manufactured by PTR HARTMANN, featuring a 5mm pitch and parallel or vertical wire connection. The terminal blocks are rated up to 8A, making them suitable for a wide range of PCB applications.

  • 2 pole
  • 5.00mm pitch
  • Connects onto pin strips on circuit boards
  • Parallel or vertical wire connection
  • Horizontal or vertical plugging on pin strip
  • Material: PA66
  • Rating: 8A 300V
  • Wire size: 22-12AWG
  • Specification
    Back order lead time 10 Days
    Colour Grey
    Contact material Copper Alloy
    Current rating 8A
    Housing material PA66
    Mounting type Cable Mount
    Number of ways 2
    Operating temperature -40°C to +105°C
    Pitch 5.00mm
    Termination method Screw
    Voltage rating 300VAC
    Wire range 22-12AWG
    Request a quote
