2.2nF 100V Polypropylene 5mm Capacitor ±2.5% Wima FKP2
by Wima
SKU 482404
MPN: FKP2-2.2N/100
Availability:
412 in stock
Original price
£0.45
-
Original price
£0.45
Original price
£0.45
£0.45
-
£0.45
Current price
£0.45
2.2nF 100V polypropylene capacitor from the Wima FKP2 series, featuring very low dielectric absorption suitable for high frequency applications including sample and hold, timing, LC-filtering, oscillating circuits and audio equipment.
Pulse duty construction Very low dissipation factor Negative capacitance change versus temperature Terminal pitch: 5mm Body dimensions: 4.5 x 6 x 7.2mm Tolerance: ±2.5% Enclosure material: self-extinguishing, UL94V-0 Maximum operating voltage: 100V DC, 63V AC
Specification
| Back Order Lead Time | 5 Days |
| Capacitance | 2.2nF |
| Height | 6mm |
| Length | 7.2mm |
| Material | Polypropylene |
| Mounting Style | Through Hole |
| Operating Temperature | -55°C to +100°C |
| Pitch | 5mm |
| Tolerance | ±2.5% |
| Voltage Rating | 63VAC / 100VDC |
| Width | 4.5mm |
