1M Linear 24mm Mono Potentiometer

SKU 481851

MPN: 481851

160 in stock
Original price £0.90 - Original price £0.90
Original price
£0.90 Inc VAT
£0.90 - £0.90
Current price £0.90 Inc VAT
1M mono potentiometer featuring a 24mm diameter base and solder lug terminals, suitable for panel mount applications.

  • Resistance: 1M
  • Taper: linear
  • Resistance tolerance: ±20%
  • Solder lug terminals
  • 6mm splined shaft
  • Panel cut-out: 8.2mm
  • Shaft length: 12mm
  • Base diameter: 24mm
  • Specification
    Back order lead time 45 Days
    Dimensions 24mm Diameter
    Maximum voltage 250VAC
    Mounting hole diameter 8.2mm
    Mounting type Panel Mount
    Operating temperature -20°C to +70°C
    Power rating 0.2W
    Resistance 1MΩ
    Shaft diameter 6mm
    Taper Linear
    Termination type Solder Lug
    Tolerance ±20%
    Total rotation 300°
