15-Way Single Row Right Angle PCB Socket 2.54mm

SKU 329036

MPN: 329036

Availability:
1237 in stock
Original price £0.44 - Original price £0.44
Original price
£0.44 Inc VAT
£0.44 - £0.44
Current price £0.44 Inc VAT
Right-angle type single row sockets with a 2.54mm pitch perfect as a removable connection for flat cables along with many other electronic applications.

  • Gold plated brass contacts
  • 0.4mm pin diameter
  • Solder termination
  • Pitch: 2.54mm
  • Pin height: 3.2mm
  • Socket height: 8.4mm
  • Specification
    Back order lead time 30 Days
    Contact material Gold Plated Brass
    Current rating 1A
    Housing material PBT
    Mounting type PCB Mount
    Number of pins 15
    Number of ways 15
    Operating temperature -40°C to +105°C
    Pitch 2.54mm
    Termination method Solder
