12V Subminiature Electromagnetic PCB Buzzer

SKU 481858

MPN: 481858

Availability:
1382 in stock
Original price £0.66 - Original price £0.66
Original price
£0.66 Inc VAT
£0.66 - £0.66
Current price £0.66 Inc VAT
12V electromagnetic buzzer housed in a subminiature package with PCB terminals. The buzzer features a sealed construction making them ideal for manufacturing applications.

  • Rated voltage: 12VDC
  • Operating voltage: 8-15VDC
  • Maximum current rating: 30mA
  • Sound output: 88db@10cm
  • Housing material: PBT
  • Pin pitch: 7.6mm
  • Dimensions: 12 x 9.5mm (Diameter x Height)
  • Specification
    Back order lead time 30 Days
    Diameter 12mm
    Height 9.5mm
    Input voltage 8-15VDC
    Mounting style PCB Mount
    Pitch 7.6mm
    Rated current 30mA
    Rated voltage 12VDC
    Sound output 88dB @ 10cm
