12V 1-Channel Relay Board Module Active Low
SKU 309022
MPN: 309022
Availability:
95 in stock
Original price
£2.10
-
Original price
£2.10
Original price
£2.10
Inc VAT
£2.10
-
£2.10
Current price
£2.10
Inc VAT
Active low relay board with 12V relays capable of being switched on-off by an opto-isolated digital input. The relays are controlled by a microcontroller connected to the output pin and require a minimum 1.5V to switch the inputs ON. Suitable for 5V and 3.3V devices, these boards are perfect for Raspberry Pi, Arduino, PIC and various other microcontrollers.
1 Channel Maximum switching voltage: 250VAC / 30VDC Maximum switching current: 10A Module operating voltage: 12V Each relay features an LED indicator Dimensions: 37 x 26 x 18mm (Length x Width x Height)
Specification
| Back order lead time | 30 Days |
| Coil voltage | 12VDC |
| Number of channels | 1 |
| Terminal type | Pin Header |
