10nF 100V Polypropylene 5mm Capacitor ±2.5% Wima FKP2
by Wima
SKU 482406
MPN: FKP2-10N/100
Availability:
94 in stock
Original price
£0.54
-
Original price
£0.54
Original price
£0.54
Inc VAT
£0.54
-
£0.54
Current price
£0.54
Inc VAT
10nF 100V polypropylene capacitor from the Wima FKP2 series, featuring very low dielectric absorption suitable for high frequency applications including sample and hold, timing, LC-filtering, oscillating circuits and audio equipment.
Pulse duty construction Very low dissipation factor Negative capacitance change versus temperature Terminal pitch: 5mm Body dimensions:6.8 x 8 x 7.2mm Tolerance: ±2.5% Enclosure material: self-extinguishing, UL94V-0 Maximum operating voltage: 100V DC, 63V AC
Specification
| Back order lead time | 5 Days |
| Capacitance | 10nF |
| Height | 8mm |
| Length | 7.2mm |
| Material | Polypropylene |
| Mounting style | Through Hole |
| Operating temperature | -55°C to +100°C |
| Pitch | 5mm |
| Tolerance | ±2.5% |
| Voltage rating | 63VAC / 100VDC |
| Width | 6.5mm |
