10K Reverse Logarithmic 16mm Stereo Splined Potentiometer

SKU 487026

MPN: 487026

Availability:
966 in stock
Original price £0.47 - Original price £0.47
Original price
£0.47
£0.47 - £0.47
Current price £0.47
10K reverse logarithmic carbon track stereo 16mm potentiometer featuring a splined 6mm shaft suitable for PCB and panel mounting.

  • Reverse logarithmic taper
  • Standard 16mm diameter metal body
  • Pin contacts
  • 20% tolerance
  • Panel cut-out: 7mm
  • 5mm terminal pitch
  • 15mm shaft length
  • 0.06W power rating
  • Specification
    Back Order Lead Time 45 Days
    Dimensions 17mm Diameter
    Maximum Voltage 150V
    Mounting Hole Diameter 7mm
    Mounting Type Panel Mount
    Operating Temperature -25°C to +70°C
    Pitch 5mm
    Power Rating 0.063W
    Resistance 10KΩ
    Shaft Diameter 6mm
    Taper Reverse Logarithmic
    Termination Type Pin
    Tolerance ±20%
    Total Rotation 300°
