100K Linear 24mm Mono Potentiometer
SKU 481848
MPN: 481848
Availability:
279 in stock
Original price
£0.81
-
Original price
£0.81
Original price
£0.81
Inc VAT
£0.81
-
£0.81
Current price
£0.81
Inc VAT
100K mono potentiometer featuring a 24mm diameter base and solder lug terminals, suitable for panel mount applications.
Resistance: 100K Taper: linear Resistance tolerance: ±20% Solder lug terminals 6mm splined shaft Panel cut-out: 8.2mm Shaft length: 12mm Base diameter: 24mm
Specification
| Back order lead time | 45 Days |
| Dimensions | 24mm Diameter |
| Maximum voltage | 250VAC |
| Mounting hole diameter | 8.2mm |
| Mounting type | Panel Mount |
| Operating temperature | -20°C to +70°C |
| Power rating | 0.2W |
| Resistance | 100KΩ |
| Shaft diameter | 6mm |
| Taper | Linear |
| Termination type | Solder Lug |
| Tolerance | ±20% |
| Total rotation | 300° |
