100µH ±10% Radial Inductor 22R104C

by Murata
SKU 552361

MPN: 22R104C

Availability:
Only 3 left!
Original price £2.11 - Original price £2.11
Original price
£2.11 Inc VAT
£2.11 - £2.11
Current price £2.11 Inc VAT
The 2200R Series is a general purpose range of inductors suitable for low to medium current applications. Their small footprint makes them ideal for high density applications where a chip inductor will not cope with the power requirement.

  • Inductance: 100µH
  • DC current: 0.67A Max
  • DC resistance: 0.39Ω Max
  • 10% tolerance
  • Radial leads
  • PCB mounting
  • Specification
    Back order lead time 5 Days
    Dc current 670mA
    Dc resistance 0.39Ω Max
    Srf 7.0MHz
    Tolerance ±10%
